Parameters |
Characteristics |
AC Charger L1 & L2 |
||||
|
Model |
SIRINX (All) |
3.3kW - 22kW |
||||
|
Input AC Power |
Rated Power |
3.3kW |
7.4kW |
11kW |
22kW |
Bharat AC 10kW |
|
Input voltage |
Single Phase, 230V AC (±10%), 50/60Hz |
Three Phase, 415V AC (±10%), 50/60 Hz |
||||
|
Max Input Current (Phasewise) |
16A |
32A |
16A |
32A |
16A |
|
|
Wires |
3 Wires AC (L, N, PE) |
5 Wires AC (L1, L2, L3, N, PE) |
||||
|
AC Power Input |
No. of charging outputs / guns |
1 No. |
3 Nos. |
|||
|
Output Rating |
230V AC, 16A Max. |
230V AC, 32A Max |
415V AC,16A Max |
415V AC,32A Max. |
Each outlet 230V AC 16A Max. |
|
|
Output Connector Type |
Industrial socket (IEC 60309) / IEC 62196, Type 2 (If provided with charging cable) |
IEC 62196-2 Type 2 (with charging cable) |
16A Industrial socket (IEC 60309) |
|||
|
User Interface & Control functions |
Display |
20X4 Character LCD (4.3” Graphics LCD avaiable upon request) |
||||
|
Languages- Supported |
English (Other Languages on request) |
|||||
|
Push Button |
Emergency Stop (Mushroom Red) |
|||||
|
RFID Reader |
As per ISO/IEC 14443 |
|||||
|
User Authentication |
via RFID card / QR code Scan / Mobile App (Via OCPP interface) |
|||||
|
Visual LED Indications |
Presence of Input Supply, Errors Indicator, State of Charge |
|||||
|
Metering and Billing |
Grid responsive AC metering and billing. |
|||||
|
Payment options |
via Mobile App Wallet / Other payment Services |
|||||
|
Charging Options |
Mode selection based on Amount/Time/kWh |
|||||
|
Charging Modes |
1. via OCPP ( for CMS & Mobile App) 2. RFID + OCPP ( Fast authorization of Tag via OCPP) 3. RFID only (Offline) 4. Plug & Play (Offline and No user authorization) |
|||||
|
Communication |
Between Charger and CMS |
Wi-Fi, LAN/4G + OCPPv1.6 |
||||
|
Between EV Charger and EV |
As per IEC 62196 |
As per BEVC- AC001 Specification |
||||
|
Environment |
Operating Temperature |
-20°C to +55°C |
||||
|
Storage Temperature |
-40°C to +70°C |
|||||
|
Altitude |
< 2000 mtr |
|||||
|
Humidity |
5% to 95%,non-condensing |
|||||
|
Protection and Safety |
Input/Output protection |
Over & Under voltage protection Overload & Short circuit protection Residual Leakage Current & Ground Fault protection Grounding / Earthing protection Surge protection Over/Under temperature Protection Emergency Stop Switch Protection against electric shock |
||||
|
Safety As per |
IEC 61851-1:2017, IEC 61851-21-2 |
|||||
|
Mechanical |
Ingress Protection |
IP5X (IP6X available only on order) |
||||
|
Enclosure Protection |
IK10 |
|||||
|
Charging Cable Length |
5 Mtrs (With Retractable cord) |
|||||
|
Cooling |
Natural / Forced Air Cooling |
|||||
|
Mounting |
Wall / Pedestal Stand |
|||||
|
Disclaimer: Charger specifications are subject to change based on customization. Note : Charger Specifications are subject to change. |
||||||
Note : Charger Specifications are subject to change.
